TS-990S
242
SPECIFICATIONS
General
Frequency range (Transmitter)
160 m band 1.8~2.0MHz (K type)/ 1.81~2.0MHz (E type)
80 m band 3.5~4.0MHz (K type)/ 3.5~3.8MHz (E type)
60 m band *4 5.1675MHz, 5.25~5.45MHz (K type)/ 5.25~5.45MHz (E type)
40 m band 7.0~7.3MHz (K type)/ 7.0~7.2MHz (E type)
30 m band 10.1~10.15MHz
20 m band 14.0~14.35MHz
17 m band 18.068~18.168MHz
15 m band 21.0~21.45MHz
12 m band 24.89~24.99MHz
10 m band 28.0~29.7MHz
6 m band 50.0~54.0MHz (K type)/ 50.0~52.0MHz (E type)
Frequency range (Receiver) *1 0.13~30MHz, 50~54MHz (VFO: Continuous 30kHz~60MHz)
Mode A1A (CW)/ A3E (AM)/ J3E (SSB)/ F3E (FM)/ F1B (FSK)/ G1B (PSK)
Frequency stability 0°C ~ 50°C Within ±0.1ppm
Antenna impedance 50
Antenna tuner load range 16.7
~150
Standard voltage AC 120V (60Hz) (K type)/ AC 220-240V (50/60Hz) (E type)
Supply voltage range
AC 90V~132V (K type)
AC 198V~264V (E type)
Power consumption
Transmit (max.) 720VA or less (K type)/ 840VA or less (E type)
Receive (no signal) 120VA or less (K type)/ 200VA or less (E type)
Usable temperature range 0°C~+50°C (+32°F~+122°F)
Dimensions
Without projection W 460 x H 165 x D 400 mm (W 18.11 x H 6.50 x D 15.75 in)
Include projection W 460 x H 182 x D 449 mm (W 18.11 x H 7.17 x D 17.68 in)
At front leg up position Front panel: H 201 mm (H 7.91 in)/ Rear panel: H 173 mm (H 6.81 in)
Weight Approx. 24.5 kg (54.01 lbs)
Transmitter
Output power SSB/CW/FSK/PSK/FM (AM) 200W (50W)
Modulation SSB: Balanced, AM: Low power, FM: Reactance
Maximum frequency deviation (FM) Wide: ±5kHz or less, Narrow: ±2.5kHz or less
Spurious emissions
HF (harmonics): –60dB or less
HF (others): –50dB or less
50MHz: –66dB or less
Carrier suppression (SSB) –60dB or less
Unwanted sideband suppression –60dB or less
Transmit frequency response Within –6dB (300~2700Hz)
Microphone impedance 600
XIT variable range ±9.999kHz
