Appendix
Standard tightening torques
Information
Tolerances of the indicated tightening torques: 10%.
Always lubricate the thread before tightening these parts (engine oil).
Fig. 136: VSTI screw plugs with ED seal (left), with o-ring (right)
Size Tightening torque Size Tightening torque
1)
VSTI ED VSTI o-ring
1)
VSTI ED VSTI o-ring
M8x1 8 Nm
6 ft-lb
8 Nm
6 ft-lb
G 1/8 10 Nm
7 ft-lb
-
M10x1 10 Nm
7 ft-lb
16 Nm
12 ft-lb
G 1/4 25 Nm
18 ft-lb
-
M12x1.5 20 Nm
15 ft-lb
28 Nm
21 ft-lb
G 3/8 50 Nm
37 ft-lb
-
M14x1.5 28 Nm
21 ft-lb
36 Nm
27 ft-lb
G 1/2 65 Nm
48 ft-lb
-
M16x1.5 40 Nm
30 ft-lb
44 Nm
32 ft-lb
G 3/4 112 Nm
83 ft-lb
-
M18x1.5 52 Nm
38 ft-lb
56 Nm
41 ft-lb
G 1 160 Nm
118 ft-lb
-
M20x1.5 60 Nm
44 ft-lb
64 Nm
47 ft-lb
G 1 1/4 320 Nm
236 ft-lb
-
M22x1.5 72 Nm
53 ft-lb
80 Nm
59 ft-lb
G 1 1/2 360 Nm
266 ft-lb
-
M24x1.5 72 Nm
53 ft-lb
- - - -
M26x1.5 100 Nm
74 ft-lb
- 3/4-16 UNF 56 Nm
41 ft-lb
-
M30x1.5 192 Nm
142 ft-lb
- 7/8-1/4 UNF 80 Nm
59 ft-lb
-
M27x2 105 Nm
77 ft-lb
135 Nm
100 ft-lb
R 3/4" 112 Nm
83 ft-lb
96 Nm
71 ft-lb
M30x2 - 172 Nm
127 ft-lb
- - -
M33x2 180 Nm
133 ft-lb
250 Nm
184 ft-lb
- - -
M42x2 290 Nm
214 ft-lb
265 Nm
195 ft-lb
- - -
M48x2 290 Nm
214 ft-lb
335 Nm
247 ft-lb
- - -
200
© 2022 by Kohler Co. All rights reserved.
KD62V12 33521030301_8_1 EN_US 2022-09
