Transportation - Storage
Dimensions and weight
3.2 Dimensions and weight
Information
The manufacturer of the machinery is responsible for the lifting, handling, and storage of the
engine.
For the latest engine dimensions and weights, refer to the “Installation Drawing”. (For more
information see: 8 Appendix, page 170.)
WARNING
Crushing, impact, shearing, part ejection hazards by load movement or lifting devices failure.
Guiding the moving load by hand could cause serious injury or death by crushing or shearing.
Lifting the entire machinery could cause serious injury or death by crushing, impact, or parts
ejection.
Falling load could cause serious injury or death by crushing, impact, or parts ejection.
Failure of lifting devices could cause serious injury or death by ejection of parts, crushing, and
impact.
u It is forbidden to guide the load by hand.
u Use the lifting hooks to lift the engine only.
u Use only adapted lifting devices in good shape.
u Check and replace the lifting devices according to local regulations.
u Respect a safe distance while lifting and moving the load.
u It is forbidden to pass under the load.
NOTICE
Falling/hanging lifting devices on the engine.
Falling/hanging lifting devices could result in property damage by impacts or tearing.
u Check and replace the lifting devices according to local regulations.
u Move the lifting devices near the engine cautiously.
KD62V12 33521030301_8_1 EN_US 2022-09
© 2022 by Kohler Co. All rights reserved.
55
