OPERATION
DETAILED CONTROLS AND GAUGES
3-105
AUXILIAR
Y ELECTRIC POWER
3
24V Power Source
3
NOTIC
E
Do not use this as the power supply fo
r 12V equipment.
It will cause failure of the equipm
ent.
Pull out the connector plug for
taking out electric power
from
the rear sid
e of the panel.
Maximum usable electric power is 85 W (24 V x 3.5 A).
12V Power Source
3
(If equipped
)
This power source can be used up to a cap
acity of 60W (12V x
5A).
170
172
