MACHINE OPERATIONS AND CONTROLS OPERATION
3-146
STEERING THE MACHINE 3
Steering 3
WARNING
Before operating the travel levers or travel pedals, check the direction that the track frame is facing (the
position of the sprocket).
When the sprocket is at the front, the direction of operation of the travel levers or control pedals is the
opposite from the direction of movement of the machine.
Use the travel levers to change direction.
Avoid sudden changes of direction as much as possible. Espe-
cially when performing counter-rotation (spin turn), stop the
machine before turning.
Operate two travel levers (1) as follows.
Steering the Machine when Stopped
When turning to the left:
Push the right travel lever forward to turn to the left when trav-
eling forward; and pull it back to turn left when traveling in
reverse.
(A): Forward left turn
(B): Reverse left turn
REMARK
When turning to the right, operate the left travel lever in the
same way.
To Next Page
