MAINTENANCE
MAINTENANCE PROCEDURE
4-49
EVER
Y 250 HOURS MAINTENANCE
4
Maintenance for every 50 hou
rs service should be carried out at the sa
me time.
LUBRICA
TE SWING CI
RCLE
4
1.
Lowe
r the work e
quipment t
o the grou
nd.
2.
Using a grease pump, pump in grease thr
ough the grease
fittings shown by arrows. (2 places)
3.
After greasing, wipe
off any old gr
ease that was pushed
out.
