FOREWORD
SAFETY INFORMATION
1-5
Noise emission levels
1
T
wo labels indicating the machine noise
level are af
fixed on the
machine.
q
Sound pressure level at
the operator’s station, mea
sured
according to ISO6396 (Dynamic
test method, simulated
working cycle).
q
Sound power lev
el emitted by the mac
hine, measured
according to ISO 6395 (Dynamic test method, simulated
working cycle). This is t
he guaranteed value as specified
in European dir
ective 2000/14/EC.
107
