OPERATION 3.4 ELECTRONIC MONITORING AND CONTROL SYSTEM ECS
101
3.4.2 OPERATING THE ELECTRONIC MONITORING SYSTEM
1.0 TEXT DISPLAY (A) with integrated KEY BOARD (B)
illust. Z25237
After switching on the Shovel’s key operated main switch, the fol-
lowing introductory messages will be displayed on screen (A):
1
st
. # Please be Safety Conscious when working!
This message will be displayed for approximately 10 seconds.
2
nd
. |QUI| Did you check the Operating Safety of the
Shovel?
Press the ”QUI” key (10) to acknowledge this message.
3
rd
. |QUI| Did you do Maintenance according to the Ser-
vice Literature?
Press the ”QUI” key (10) to acknowledge this message. Thereaf-
ter the basic ECS display normally automatically appears on the
screen (A) if no information - or fault messages are present.
Present information - or fault messages overwrite the introductory
messages no. 2 and 3.
*1) M1 = Short form for Rear Engine on counterweight
side designated as Engine 1.
*2) M2 = Short form for Front Engine on Operator’s cab
side designated as Engine 2.
All messages related to one of the two engines, their connected
cooling systems and pump distributor gears are identified by the
figure 1 or 2.
Example of an engine related message:
This message applies to the rear engine on counterweight side
”Engine 1”.
-0-
Date h: M1 *1) 1/min:
Time M2 *2) 1/min:
Fault No. 560:
(563)
$h: Shut down of engine 1: oil pressure at low idle too
low
Help: Message through sensor B1-1.
.
