3.4 ELECTRONIC MONITORING AND CONTROL SYSTEM ECS OPERATION
172
3.4.6 FAULT AND INFORMATION MESSAGE LIST
The messages are divided into four groups as follows:
Explanation of Control Signs shown at the beginning of the
first text line:
Group 1
The fault messages of group 1 will be stored and result
in:
● Start blocked condition or
● Automatic engine speed reduction to low idle or
● Automatic shutdown of the Shovel or
● Attention of Service Staff required.
Message page numbers of start blocked condition:
● 500, 506, 536, 542, 578, 596, 608, 620, 626, 638,
644, 650, 656, 704 and 728.
Message page numbers of automatic engine speed
reduction to low idle:
● 524, 602, 614, 662, 668, 674, 680 and 686.
Message page numbers of shutdown conditions:
● 548, 560, 590, 632 and 716.
Message Text Pages:
500 - 739
Group 2 The fault messages of group 2 will be stored.
The following messages will result in automatic engine
speed reduction to low idle:
● 1286, 1292, 1298 and 1304.
Message Text Pages:
740 - 1309
Group 3 The fault messages of group 3 will be stored. Message Text Pages:
1310 - 1319
Group 4 The fault messages of group 4 will not be stored. Message Text Pages:
1320 - 1535
$ :
The Dollar sign serves as a reference signal for on-
line data transfer on machines using the Modular
Mining Dispatch System ”MMS”.
# : Message will not be stored.
? :
Recording of this message in the protocol memory is
accomplished with ”COMING” registration only.
