4.4 FILLING CAPACITIES MAINTENANCE
316
4.4 FILLING CAPACITIES
*1) Oil change quantity including suction oil tank and return oil col-
lector pipes approximately 4450 liter with loader attachment in oil
level checking position, see oil level plate on the main hydraulic
oil reservoir.
*2) Fill up to level gauge marking.
EMARK
Capacities listed above are approximate values.
For proper checking use level plugs, dipsticks, and inspection
openings provided for this purpose. Prior to commissioning check
the fluid levels in all units and systems listed above.
Unit or System
Liter
(approx.)
Unit or System
Liter
(approx.)
Cooling System Swing Gears made by L&S, each: 42.0
Front Engine 360.0 Motor Adapter Housings 0.6
Rear Engine 360.0
Swing Gears made by Sieben-
haar, each: 60.0
Engine Oil Motor Adapter Housings *2)
Front Engine Oil Pan 190.0 Brake Housings *2)
Front Engine Reserve
Tank (Refill)
580.0
(425.0)
Travel Gears, each 155.0
Rear Engine Oil Pan 190.0 Motor Adapter Housings, each 2.0
Rear Engine Reserve
Tank (Refill)
580.0
(425.0)
EMARK
The travel gear brakes are dry
type multiple disk brakes. DO NOT
fill the housings with oil.
Fuel Tank 10800.0 Final drive housings, each 165.0
Hydraulic Oil Reservoir 3600.0 *1) Guide Wheels, each 3.2
Total Hydraulic System 6600.0 Support Rollers, each 7.0
Pump Distributor Gears,
each
95.0 Track Rollers, each 2,7
Oil Collector Reservoir,
Auxiliary Hydraulic Pumps
1.0
Water tank for hand wash sink in
Operator’s cab
50.0
Main Hydraulic Pumps,
Drive Shaft Housing
1.5
Water reservoir for windshield
washer
7.0
Flexible Drive Couplings
between Engine and
Pump Distributor Gear,
each
1.45
