MAINTENANCE 4.11 EVERY 500 OPERATING HOURS OR QUARTERLY
403
4.11.5 GROUND CABLES OF ENGINE AND ALTERNATOR - CHECK FOR
CORRECT CONNECTION
Legend for illustration Z25498
Check ground cables
1. Remove both battery main switch keys.
2. Check ground strap (1) and ground cable (2) on both engines
for good condition and secure fastening.
WARNING
● Be sure to replace a worn or damaged cable or fastening
part without delay.
● Loose or missing ground cables can cause fire, serious
injury or death.
(A) Alternator seen from below
(B) RH member of engine carrier frame
(1) Ground strap from engine to the ground terminal of
alternator (A)
(2) Ground cable from alternator (A) to RH member of
engine carrier frame (B)
(3) Identification plate (GND) for ground cables
To Next Page
