OPERATION 3.22 TRANSPORTATION AND LIFTING OF THE SHOVEL
299
3.22 TRANSPORTATION AND LIFTING OF THE
SHOVEL
WARNING
Before Disassembling, Lifting or Transporting this Shovel
contact your local Komatsu Service Station for all the neces-
sary instructions for safe and economic disassembling, lift-
ing and transportation procedures of your Shovel.
3.22.1 DISASSEMBLING OF THE SHOVEL
The Shovel is being transported disassembled into its main com-
ponents.
WARNING
Disassembling of the Shovel must be carried out only by per-
sonnel with special knowledge of the Shovel. Improper dis-
assembling procedures can cause severe accidents with
personal injury.
The sequence of disassembly can be derived from the Assembly
Procedure Manual in volume 2 Binder. Disassembling is basically
the reverse order of the assembling procedure.
3.22.2 TRANSPORTATION AND LIFTING
The transport dimensions and weights of the Shovel’s compo-
nents are listed in the separate Assemby Procedure Manual filed
in volume 2 binder.
Observe the operating permits of the low loader used for trans-
portation. They contain the permissible load, loading width and
height.
WARNING
● Observe the federal, state and local laws and regulations
for transportation of heavy units. Know the safety rules
and laws before you transport this Shovel.
● Make sure the low loader and the components of the
Shovel are equipped with the correct safety devices.
● Secure the Shovel and all components transported on
the low loader against movement.
