OPERATION 3.3 OPERATOR’S CAB - CONTROLS
81
3.3.3 OPERATOR’S CONSOLE
Legend for illustration Z25500
CAUTION
Make sure the cab door is always closed when working with
the Shovel.
Secure the door in open position with the locking device pro-
vided.
(1) Analog gauges, see page 83 for more information
(2) Text display with key board of the Electronic Control
and Monitoring System (ECS). Refer to page 92 for
more information.
(3) Ashtray
(4) Switch board, see page 83 for more information
(5) Switch for adjustment of left and right cab mirror
(6) Control unit for air conditioning and heating, see
page 198 for more information
(7) Cigarette lighter
(8) Plug sockets 24V DC
(9) Radio
(10) Switch board lighting with flexible arm
