FUSES
• Parts of the electrical system may be damaged, if you re-
place fuses with the ignition switched on!
Turn the start switch to switching position '0' (OFF), be-
fore starting to replace fuses.
• Fuses with wrong amperages may cause fires due to elec-
trical faults or may immediately blow again!
Only replace defective fuses with fuses of the same rat-
ing.
The fuses protect the electrical system. Replace defective, cor-
roded, or loose fuses.
The fuses are located under the cover. To access the fuses, re-
movethescrewsfixingthecoverandremovethecover.Thenre-
move the cover caps of the fuse boxes.
FUSE ASSIGNMENT
1 Starter, stop magnet, socket 10A Solenoid valves gear unit 10A
2 Inside lighting, radio 10A Direction indicator, horn 10A
3 Hazard flasher 10A Instrument lighting 10A
4
Windscreen wiper and windscreen washer
front and rear
20A
Working light
20A
5
Brake light, reversing warning system,
warning beacon
10A
Side lamp left, lamp registration number
10A
6 Fan, ventilation, heating 20A Side lamp right 10A
7 Heated rear windscreen 20A High beam 10A
8
Tank sensor, solenoid valves high speed-
motor, ALS (option)
10A
Low beam
10A
