13 Technical data
13.1 Dimensions and weights
The technical data can vary depending on
the vehicle equipment. A list of the tech-
nical data for all variants is not possible
here. The vehicle-specific technical data is
noted in the vehicle documents. The meas-
urements and weights in the following table
refer to the basic vehicle model.
Technical data
Pump weight
7.35kg
Flow rate
25cm³/stroke
Tank capacity
3 litres
max. perm. pressure
250bar
Temperature range
-40°C/+70°C
2-axle turnframe trailer (AZP18eL4-CS)
Dimensions and weights
Permitted total weight
18,000 kg
Axle load
18,000 kg
Dead weight
approx. 4,170
kg
Unladen ride height
1,300 mm
Wheelbase
4,870 mm
Construction height, front
140 mm
Draw fork length
2,200 mm
Internal clearance length
7,100 mm
Internal clearance width
2,480 mm
Clear lateral loading height
2,600 mm
Outer width
2,550 mm
3-axle turnframe trailer (ADP27eL4-CS)
Dimensions and weights
Permitted total weight
24,000 kg
Axle load
24,000 kg
Dead weight
approx. 5,340
kg
Unladen ride height
1,300 mm
Wheelbase
5,340 mm
Construction height, front
140 mm
Dimensions and weights
Draw fork length
2,050 mm
Internal clearance length
8,600 mm
Internal clearance width
2,480 mm
Clear lateral loading height
2,600 mm
Outer width
2,550 mm
Central axle trailer (ZZP18eL4-CS)
Dimensions and weights
Permitted total weight
18,000 kg
Axle load
18,000 kg
Dead weight
approx. 4,830
kg
Unladen ride height
1,210 mm
Wheelbase
1,810 mm
Drawbar wale length
2,250 mm
Internal clearance length
7,300 mm
Internal clearance width
2,480 mm
Clear lateral loading height
2,675 mm
Outer width
2,550 mm
Further information can be found on our
website www.krone-trailer.com.
13.2 Plugs and socket pin as-
signments
13.2.1 Connector
Turnframe trailers are equipped with plugs.
The function and arrangement of the con-
tact pins in the plug are identical to the ar-
rangement of the contact openings in the
socket.
