LOADING AND SECURING
98
Operating instructions • Load Carrier • 505410638-02 • 07/2019
Other load securing systems can be
fastened in the Multi Lock external frame,
e.g. Multi Block or Multi Wall.
8.7.2 Using the Multi Lash lashing
rings
KRONE trailers can be equipped with Multi
Lash lashing rings. The pivoting lashing
rings allow a tension strap to be attached
above the exterior frame and thus, even
extremely flat loads can be secured.
1 2
Fig.8-7: Multi Lash with Multilock external
frame
1 Multi Lash lashing ring
2 Hole
The Multi Lash lashing rings can be flexibly
screwed into the existing holes in the Multi-
lock external frame (see "8.7.1 Using the
Multi-Lock external frame", pg.97). Multi Lash
can support loads up to 2,000daN.
8.7.3 Using the Multi Flex chain ad-
apter
KRONE trailers can be equipped with Multi
Flex chain adapters. The chain adapter en-
ables the use of many different hook
shapes on the lashing belts and lashing
chains.
Fig.8-8: Multi Flex chain adapter with Mul-
tilock external frame
The Multi Flex chain adapter is locked with
two hooks onto the Multi Lock external
frame (see "8.7.1 Using the Multi-Lock external
frame", pg.97). It can sustain loads up to
4,000 daN.
Inserting the Multi Flex chain adapter
2
1
Fig.8-9: Multi Flex chain adapter
1 Hook mount
2 Hook for Multi Flex chain adapter
► Attach the hook for the Multi Flex chain
adapter to the lashing holes on the
Multilock external frame.
