Krone LOAD CARRIER User Manual

INFORMATION ABOUT THIS DOCUMENT
8
Operating instructions • Load Carrier • 505410638-02 • 07/2019
The type plate is attached to the following
location for product identification:
L:
Typ
mm
kg
kg
kg
kg
1-
Fahrzeugwerk Bernard Krone GmbH & Co. KG
2-
3-
kg
kg
kg
kg
kg
1-
2-
3-
kg
W: mm
b/b
MAX : mm
b
MIN : mm
2
1
Fig.1-1: Type plate attachment points
1 Standard
2 Alternative
The following information is shown on the
type plate:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Fig.1-2: Example type plate
1 Manufacturer
2 EC type approval number (if available)
3 Vehicle ID number
4 Approved total mass
5 Total mass on the coupling point
6 Technically approved axle loads
7 Technically approved total mass
8 If applicable, the nationally approved
total masses for registration/operation
including the code
9 If applicable, dead weight
10 Min. distance
11 Distance/max. distance
12 Vehicle width
13 Vehicle length
14 If applicable, national type approval no.
15 Type designation
1.4 Retention of documents
► Store these instructions and all other
applicable documents in a safe place.
► Pass the complete documentation on
to the next driver or owner.
1.5 Part positions
The description of part positions is always
viewed in forward driving direction.
1.6 Optional components
KRONE trailers are fitted with a number of
optional components. The operating in-
structions describe all of the components in
the following sections.
All the components are not necessarily on
your trailer.
1.7 Symbols used in these in-
structions
Various markings and symbols are used in
the text in these instructions. These are ex-
plained below.
○ Bullet list
– Sub-list
1. Numbered list
þ Prerequisite for action
► Action step
ð Intermediate action result
ü Result of the action
INFO
Additional information and tips.
