SUPERSTRUCTURE OPERATION
Operating instructions • Load Carrier • 505410638-02 • 07/2019
59
► Press the right door lock lever in the
vehicle direction. If there are two door
locks on one door leaf, unlock the door
locks successively.
► Open the anti-tilt device.
► Swivel out the door lock lever so that
the tension bolts push the door open.
► Open the door leaf.
► Swivel the door lock lever back to the
original position.
► Secure the swivelled open door leaves
with door stops (see "6.1.3 Door stop and
Door Fix", pg.59).
ð The right-hand door lock is
opened.
► Open the left door lock in the same
way.
ü Both door locks are opened and
fastened.
Closing the door locks
► Release the left door stop (see "6.1.3
Door stop and Door Fix", pg.59).
► Close the door leaf.
► Swivel in the door lock lever so that
the tension bolts pull the door closed.
► Attach the curtain rope.
ð The left-hand door lock is closed.
► Close the right door lock in the same
way.
ü Both door locks are closed.
6.1.3 Door stop and Door Fix
CAUTION
Risk of accident due to the doors
swinging uncontrollably!
Unlocked doors can swing out and injure
people and cause material damage.
► Always secure open doors with door
stops.
► Close and secure doors prior to de-
parture.
► Door stops are not intended for driv-
ing with opened doors. Follow the ad-
ditional instructions (see "7.5 Driving
with open doors", pg.92) when driving
with open doors.
CAUTION
Risk of crushing when operating the
door stop!
The spring-loaded door stop can spring
back and crush fingers and hands.
► Wear work gloves.
► Grab the door stop as far below the
curve as possible during use.
Securing the door with the door stop
1
2
Fig.6-5: Pulling the door stop outwards
1 Door leaf swung open
2 Door stop
► Pull out the door stop against the
spring force.
