RUNNING GEAR OPERATION
46
Operating instructions • Load Carrier • 505410638-02 • 07/2019
► Lift the telescopic ladder and place it
on the lock.
ü The telescopic ladder is inserted and
secured.
5.13.4 Fold-down steps
KRONE trailers with a folding rear wall and
folding side walls can be equipped with
fold-down steps.
Fig.5-34: Fold-down steps on the folding
rear wall
1 Fold-down steps
► Fold out the fold-down steps before
use.
► Use hand straps for mounting and dis-
mounting (see "5.13.1 Hand strap",
pg.44).
► Fold in the fold-down steps again after
use.
5.14 Side collision protection
WARNING
Risk of accident when driving with the
side collision protection folded up!
Driving with the side collision protection
folded up is not permitted by law. In a col-
lision, other motorists can get below the
trailer and be fatally injured.
► Only drive with the side collision pro-
tection folded down and locked in
place on both sides.
NOTE
Material damage when loading the
trailer!
A folded-down side collision protection
can cause material damage to the trailer
when loading the trailer (e.g. during rail
transport).
► Fold up and lock the side collision
protection on both sides when loading
the trailer.
KRONE trailers have a side collision pro-
tection. In addition to the fixed version, the
folding version provides the possibility of
folding up the side collision protection for
maintenance work, to remove tools, to
change the spare wheel or similar.
5.14.1 Folding side collision protec-
tion with lock
CAUTION
Risk of injury from the side collision
protection folding down unintention-
ally!
An unlocked side collision protection can
suddenly fold down and injure people or
swing outwards while driving, thereby
causing accidents.
► Lock the side collision protection in
every position.
Fig.5-35: Folded-down side collision protec-
tion ((rear view))
1 Drilled hole for the plug-in bolt while
folded up
2 Plug-in bolts with spring pin
