RUNNING GEAR OPERATION
Operating instructions • Load Carrier • 505410638-02 • 07/2019
51
► Insert the defective wheel in the spare
wheel bracket and secure it (see "5.15
Spare wheel bracket", pg.47).
ü The spare wheel has been mounted.
► Check the tyre inflation pressure of the
spare wheel used.
5.16 Storage box
WARNING
Risk of accident when driving with an
open storage box!
If the storage box lid is open, objects may
fall out and cause accidents.
► Only drive with the storage box closed
and secured.
CAUTION
Risk of injury due to falling objects!
When the storage box is opened, objects
may fall out and injure people.
► Be careful when opening the storage
box and watch for falling objects.
The storage box is mounted underneath
the trailer. The storage box is part of the
side collision protection or replaces the
side collision protection.
Fig.5-39: Storage box
1 Tension lock
2 Spring cotter pin
Opening the storage box
► Remove the spring cotter pin.
► Open the tension locks.
► Fold the lid down.
ü The storage box is open.
Closing the storage box
► Fold the lid up.
► Close the tension locks.
► Secure the tension locks with spring
cotter pins.
ü The storage box is closed and se-
cured.
5.17 Pallet storage box
WARNING
Risk of accident when driving with an
open pallet storage box!
If the pallet storage box lid is open, pallets
may fall out and cause accidents.
► Only drive with the pallet storage box
closed and secured.
NOTE
Material damage when driving on un-
even ground!
When driving on uneven ground with low
ground clearance, the pallet storage box
can be damaged.
► When driving on uneven ground, en-
sure that there is sufficient ground
clearance.
On KRONE trailers with pallet storage
boxes, the lids of the storage boxes re-
place the side collision protection. The lids
of the pallet storage boxes are opened and
closed with tension locks. Depending on
the version, they are located on top or on
the side of the lid.
