SUPERSTRUCTURE OPERATION
Operating instructions • Load Carrier • 505410638-02 • 07/2019
61
1 2 3
Fig.6-10: Door lock lever engaged in the
Door Fix
1 Door Fix
2 Lever for Door Fix
3 Door lock lever
► Turn the door lock lever forwards to-
wards the direction of travel.
► Engage the door lock lever in the Door
Fix device.
ü The Door Fix is engaged.
Releasing the Door Fix
► Slide the lock on the Door Fix device
towards the centre of the vehicle.
► Pull out the door lock lever from the
lock.
ü The Door Fix is released.
6.1.4 Rear wall
!
WARNING
Risk of accident due to loss of load!
If the rear wall is unlocked and unsecured,
load falling out while driving can result in
personal injury and material damage.
► Check that the rear wall is locked be-
fore every trip.
CAUTION
Risk of injury due to the rear wall un-
controllably folding down!
An unlocked and unsecured rear wall can
suddenly fold down and cause personal
injury and material damage.
► When unlocking the last lock, hold
onto the rear wall with one hand.
CAUTION
Risk of accident due to folded-down
rear wall!
A folded-down rear wall can cover the
lighting equipment. This can cause rear-
end collisions while driving and with
parked trailers, causing material damage
and personal injuries.
► Drive and park only with a properly
closed and secured rear wall.
CAUTION
Risk of injury from falling loads!
Loads falling out can injure people and
cause material damage when the doors or
rear walls are opened, particularly with
double-deck loading.
► When opening the doors or rear walls,
always watch out for falling loads.
Depending on the version, the rear wall of
the KRONE trailer is equipped with
between two and four locks.
Folding down the rear wall
► If necessary, remove the curtain rope
and curtain on the rear end of the
vehicle.
