23 TECHNICAL DATA
118
Sport 5 clicks
Full payload 10 clicks
Static sag 12 mm (0.47 in)
Riding sag 34 mm (1.34 in)
Spring rate
Medium (standard) 150 N/mm (857 lb/in)
Spring length 180 mm (7.09 in)
Inbuilt length 307 mm (12.09 in)
Gas pressure 16 bar (232 psi)
Shock absorber oil Shock absorber fluid (SAE 2.5)
(50180751S1) ( p. 122)
23.8.2 ASEAN/CN/PH
Shock absorber article number S20135701O
Shock absorber WP Suspension
Spring preload
Standard 3 clicks
Static sag 12 mm (0.47 in)
Riding sag 34 mm (1.34 in)
Spring rate
Medium (standard) 150 N/mm (857 lb/in)
Spring length 172 mm (6.77 in)
Fitted length 298 mm (11.73 in)
Gas pressure 16 bar (232 psi)
Shock absorber oil Shock absorber fluid (SAE 2.5)
(50180751S1) ( p. 122)
23.9 Chassis tightening torques
Screw, chain guard EJOT PT
®
K60x30 3 Nm (2.2 lbf ft)
Screw, tail light M4 2 Nm (1.5 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, chain guard M5 7 Nm (5.2 lbf ft)
Loctite
®
243™
Screw, compensating tank cap
lock, rear brake
M5 9 Nm (6.6 lbf ft)
Screw, foot brake lever stub M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Nut, foot brake lever adjustment M6 10 Nm (7.4 lbf ft)
Nut, shift rod M6 6 Nm (4.4 lbf ft)
Remaining nuts, chassis M6 15 Nm (11.1 lbf ft)
Remaining screws, chassis M6 9 Nm (6.6 lbf ft)
Screw, cross connector M6 15 Nm (11.1 lbf ft)
Screw, engine guard M6 9 Nm (6.6 lbf ft)
Loctite
®
243™
