13 SERVICE WORK ON THE CHASSIS
62
402345-01
– Move the handlebar to the straight-ahead position. Position the
lifting gear.
Mounting pin (69329965030)
Front wheel work stand, large (69329965100)
Info
Always raise the motorcycle at the rear first.
– Lift the motorcycle at the front.
13.4 Taking the motorcycle off the front lifting gear
Note
Danger of damage The parked vehicle can roll away or fall over.
– Park the vehicle on a firm and level surface.
402777-01
Main work
– Secure the motorcycle against falling over.
– Remove the front lifting gear.
S04136-10
–
Mount protection cap
1
.
Finishing work
– Remove the rear of the motorcycle from the lifting gear.
( p. 61)
13.5 Cleaning the dust boots of the fork legs
Preparatory work
– Raise the motorcycle with the rear lifting gear. ( p. 61)
– Lift the motorcycle with the front lifting gear. ( p. 61)
–
Remove front fender. ( p. 70)
