CONTROLS 6
13
6.1 Clutch lever
S04142-10
The clutch lever
1
is fitted on the left side of the handlebar.
6.2 Hand brake lever
S04143-10
The hand brake lever
1
is fitted on the right side of the handle-
bar.
The front brake is engaged using the hand brake lever.
6.3 Throttle grip
S04143-11
The throttle grip
1
is fitted on the right side of the handlebar.
6.4 Switches on the left side of the handlebar
6.4.1 Combination switch
The combination switch is fitted on the left side of the handlebar.
S04151-01
Overview of the left combination switch
1
Light switch ( p. 14)
2
Menu buttons ( p. 14)
3
Turn signal switch ( p. 14)
4
Horn button ( p. 14)
