6.12 Seat lock
S04137-10
The seat lock
1
is located to the left of the seat.
The seat lock can be unlocked using the ignition key.
6.13 Tool set
S04140-10
The tool set
1
is located under the passenger seat.
6.14 Grab handles
S04141-10
The grab handles
1
are used for moving the motorcycle around.
If you carry a passenger, the passenger can hold onto the grab
handles during the trip.
6.15 Passenger foot pegs
S04131-01
The passenger foot pegs can be folded up and down.
Possible states
• Passenger foot pegs folded up – For operation without a pas-
senger.
• Passenger foot pegs folded down – For operation with a pas-
senger.
