CONTROLS 6
19
6.16 Shift lever
401950-10
Shift lever
1
is mounted on the left side of the engine.
401950-11
The gear positions can be seen in the photograph.
The neutral or idle position is between the first and second gears.
6.17 Foot brake lever
402177-10
Foot brake lever
1
is located in front of the right footrest.
The foot brake lever is used to activate the rear brake.
6.18 Side stand
402029-10
The side stand
1
is located on the left of the vehicle.
The side stand is used for parking the motorcycle.
Info
The side stand must be folded up during motorcycle use.
The side stand is coupled with the safety starting system;
follow the riding instructions.
Possible states
• Side stand folded out – The vehicle can be supported on the
side stand. The safety starting system is active.
• Side stand folded in – This position is mandatory when riding
the motorcycle. The safety starting system is inactive.
