20 TECHNICAL DATA 82
Screw, water pump cover M6 10 Nm (7.4 lbf ft) –
Nuts, cylinder base M8 20 Nm (14.8 lbf ft) –
Screw, locking lever M8 16 Nm (11.8 lbf ft) Loctite
®
243™
Oil drain plug with magnet M10 20 Nm (14.8 lbf ft) –
Primary gear screw M10x1.25 80 Nm (59 lbf ft) Loctite
®
243™
Nut, rotor M12x1 60 Nm (44.3 lbf ft) –
Nut, inner clutch hub M14x1.25 60 Nm (44.3 lbf ft) Loctite
®
243™
Spark plug M14x1.25 20 Nm (14.8 lbf ft) –
20.3 Carburetor
Carburetor type KEIHIN PWK 28
Needle position 3rd position from top
Idle air adjusting screw
Open 1.5 turns
Main jet 118
Jet needle N5HG
Idling jet 45
Needle jet 2,6
Throttle slide 3,5
Cold start jet 62

KTM 85 SX 19/16 2017 Specifications

General

Engine Type	1-cylinder, 2-stroke engine
Displacement	84.9 cm³
Starter	Kickstarter
Transmission	6-speed
Clutch	Wet, multi-disc clutch, Formula hydraulics
Front Wheel	1.60 x 19"
Rear Wheel	2.15 x 16"
Seat Height	890 mm
Cooling System	Liquid cooled
Bore x Stroke	47 mm x 48.95 mm
Frame	Central tube frame, chrome molybdenum steel
Front Suspension	WP upside-down Ø 43 mm
Rear Suspension	WP monoshock
Front Brake	Disc brake
Rear Brake	Disc brake
Wheelbase	1, 290 mm ± 10 mm
Tank Capacity	5.2 liters
