8 ERGONOMICS
108
8.1 Handlebar position
V01210-11
On the upper triple clamp there are two holes at a distance of
A
apart.
Hole distance
A
15 mm (0.59 in)
The handlebar can be mounted in two different positions. This
allows the handlebar to be mounted in the most comfortable posi-
tion for the rider.
Info
KTM recommends the front handlebar position when using
the vehicle on a race track.
8.2 Adjusting the handlebar position
Warning
Danger of accidents A repaired handlebar poses a safety risk.
If the handlebar is bent or straightened, the material becomes fatigued. The handlebar may break as a
result.
– Change the handlebar if the handlebar is damaged or bent.
