7 COMBINATION INSTRUMENT
72
The temperature indicator consists of eight bars. The more bars
that light up, the hotter the coolant.
Emergency mode operation is automatically activated at a coolant
temperature of 120 °C.
Info
When all the bars light up, the ENGINE TEMP HIGH warning
also appears.
Possible states
• The engine is cold – Up to three bars light up.
• Engine warm – Four to five bars light up.
• Engine hot – Six to eight bars light up.
• Engine very hot – All eight bars flash orange.
7.12 Trip master
H02617-01
Trip 1 is displayed in the start screen as a trip master. This cannot
be changed.
Information about the total riding distance covered can be
accessed in the General Info menu under menu item Odometer.
The trip master can be configured in the Trip 1 menu.
Information about other distances traveled can be accessed and
configured in the Trip 2 menu.
