COMBINATION INSTRUMENT 7
77
7.16.3 Trip 2
H02857-01
– Press the SET button when the menu is closed.
– Press the UP or DOWN button until the Trips/Data menu is
marked on the display. Press the SET button to open the menu.
– Press the UP or DOWN button until the Trip 2 menu is marked
on the display. Press the SET button to open the menu.
Trip 2 shows the distance since the last reset, such as between two
refueling stops. Trip 2 is running and counts up to 9999.
ØConsumption2 indicates the average consumption based on Trip 2
and Trip time 2.
ØSpeed2 indicates the average speed based on Trip 2 and
Trip time 2.
Trip time 2 shows the journey time on the basis of Trip 2 and runs
as soon as a speed signal is received.
Fuel range indicates the possible distance you can cover with the
fuel reserve.
Press and
hold the but-
ton for 3–5
seconds.
In the Trip 2 menu all entries apart from
Fuel range are deleted.
