16 ELECTRICAL SYSTEM
234
16.12 Changing the turn signal bulb
Note
Damage to reflector Grease on the reflector reduces the light intensity.
Grease on the bulb will evaporate due to the heat and be deposited on the reflector.
– Clean and degrease the bulbs before mounting.
– Do not touch the bulbs with your bare hands.
K00017-10
– Remove the screw on the rear of the turn signal housing.
–
Carefully remove turn signal glass
1
.
–
Press bulb
2
carefully into the socket, turn it counterclock-
wise by about 30°, and take it out of the socket.
Guideline
Do not touch the reflector with your fingers and keep it free
from grease.
– Push the new bulb gently into the socket and turn it clockwise
all the way in.
Turn signal (RY10W / socket BAU15s) ( p. 286)
– Check that the turn signal is functioning properly.
– Position the turn signal glass.
