Paragraph
61
Cont.
diode assembly if any are defective.
Check for continuity between N ter-
minal
(1
-
Fig.
80) and inside coil connec-
ting terminals. If open circuit is found,
renew diode assembly. If length of
brushes is less than 10.5 mm (13/32
inch),
renew brushes.
When reassembling alternator, be
sure insulating washers are installed on
positive diode holder studs
(1
-Fig. 81).
Before reinstalling rotor, insert a wire
or plastic rod through hole in end frame
(Fig. 82) to hold brushes up. Be sure to
remove wire after rotor is installed.
KUBOTA
Brush
Rotor
Wire
End franrw
Slip ring Bearing
Fig. 82—Insert a wire or plastic rod through end
frame to hold brushes up when reinstalling
rotor.
Fig, 81—Make certain insulating washers (1) are
installed on positive diode mounting studs.
Fig. 78—Checff for continuity (short circuit} across stator ieads and
stator frame.
fig, 7S'~Check diodes by placing negative probe on outside terminal
and positive probe on mounting
stud,
then reverse test iead positions.
Fig, 80—There should be continuity between inside terminals and N
terminal (1).
1
Starter
Fig, 83—Disconnect lead at C terminal of
magnetic switch, then connect battery positive
terminai directly to starter to check starter
motor operation.
15
16
Fig, 84—Exploded view of starter motor used on Model U85.
1.
Plug 14. Brush & holder
2.
Bushing assy.
3.
Drive end frame 9. Pinion gear
&
15. Bushing
4.
Drive lever clutch assy. 16. End frame
5.
Magnetic switch 10. Frame 17. Gasket
6. Armature 11. Field coil 18. Spring
7.
Snap ring 12. Brush 19. Retainer
8. Spacer 13. Brush spring 20. Cap
21
18
22
10
Fig. 85—Exploded view of starter used on Models L235, L245 and
L275. Refer to Fig. 84 iegend except for following items:
21.
Spring holder . 22. Center hearing 23. Washer
30
