STV32 · STV36 · STV40, WSM TRANSMISSION
3-S6
BI-SPEED HYDRAULIC CLUTCH AND GEARS
Item Factory Specification Allowable Limit
Clutch Disc Thickness 1.915 to 2.085 mm
0.1754 to 0.0821 in.
1.4 mm
0.055 in.
Steel Plate Thickness 0.95 to 1.05 mm
0.0374 to 0.0413 in.
0.8 mm
0.031 in.
Pressure Plate Thickness 1.95 to 2.05 mm
0.0768 to 0.0807 in.
1.8 mm
0.071 in.
Piston Return Spring Free Length 44.0 mm
1.73 in.
Load / Length 638.7 N / 26 mm
65.13 kgf / 26 mm
143.6 lbs / 1.02 in.
539.4 N / 26 mm
55 kgf / 26 mm
121.3 lbs / 1.02 in.
Counter Shaft B to 27T Gear Clearance 0.040 to 0.082 mm
0.00157 to 0.00323 in.
0.1 mm
0.004 in.
Counter Shaft B
(O.D.)
24.959 to 24.980 mm
0.98264 to 0.98346 in.
27T Gear
(I.D.)
25.020 to 25.041 mm
0.98504 to 0.98587 in.
Counter Shaft B to 32T Gear Clearance 0.040 to 0.082 mm
0.00157 to 0.00323 in.
0.1 mm
0.004 in.
Counter Shaft B
(O.D.)
28.459 to 28.480 mm
1.12043 to 1.12126 in.
32T Gear
(I.D.)
28.520 to 28.541 mm
1.12283 to 1.12366 in.
18T Gear Shaft to Bushing Clearance 0.000 to 0.062 mm
0.000 to 0.00244 in.
0.1 mm
0.004 in.
18T Gear Shaft
(O.D.)
17.989 to 18.000 mm
0.70823 to 0.70866 in.
Bushing
(I.D.)
18.000 to 18.051 mm
0.70866 to 0.71067 in.
0000008036E
KiSC issued 04, 2006 A
