STV32 · STV36 · STV40, WSM SPECIFICATIONS
7
SPECIFICATIONS
Model STV32 STV36 STV40
PTO power 17.7 kW (24.1 HP)* 20.2 kW (27.5 HP)* 22.8 kW (31.0 HP)
Engine
Maker KUBOTA
Model D1503-M D1703-M D1803-M
Type E-TVCS, water-cooled, 4-cycle diesel
Number of cylinders 3
Bore and stroke 83 x 92.4 mm (3.27 x 3.64 in.) 87 x 92.4 mm (3.43 x 3.64 in.) 87 x 102.4 mm (3.43 x 4.03 in.)
Total displacement 1499 (91.5 cu.in.) 1647 (100.5 cu.in.) 1826 (111.4 cu.in.)
Engine gross power 24.1 kW (32.3 HP)* 26.8 kW (35.9 HP)* 29.5 kW (39.5 HP)*
Rated revolution 2700 rpm
Maximum torque 99.2 (10.0 ) 108.3 (10.9 ) 120.7 (12.2 )
Battery 12 V, RC : 123 min, CCA : 490 A
Starting system Electric starting with cell starter 12 V, 1.4 kW
Lubricating system Forced Iubrication by trochoidal pump
Cooling system Pressurized radiator, forced circulation with water pump
Fuel Diesel fuel No. 2-D [above -10 (14 )], Diesel fuel No. 1-D [below 10 (14 )]
Capacities
Fuel tank 29.5 L (7.79 U.S.gals, 6.49 Imp.gals)
Engine crankcase
(with filter)
6.7 L (7.1 U.S.qts, 5.9 Imp.qts)
Engine coolant 6.1 L (6.4 U.S.qts, 5.4 Imp.qts)
Transmission case 22 L (5.81 U.S.gals, 4.84 Imp.gals)
Front axle case 4.0 L (4.2 U.S.qts, 3.5 Imp.qts)
Tires
Front
Farm:
6 - 12
Turf:
24 x 8.5 - 14
Farm:
6 - 12
Turf:
24 x 8.5 - 14
Farm:
6 - 12
Turf:
24 x 8.5 - 14
Rear 9.5 - 22 13.6 - 16 9.5 - 22 13.6 - 16 9.5 - 22 13.6 - 16
Dimensions
Overall length
(with 3P)
2860 mm (112.6 in.)
Overall width
(min. tread)
1220 mm
(48.0 in.)
1310 mm
(51.6 in.)
1220 mm
(48.0 in.)
1310 mm
(51.6 in.)
1220 mm
(48.0 in.)
1310 mm
(51.6 in.)
Overall height
(with ROPS)
2350 mm
(92.5 in.)
2340 mm
(92.1 in.)
2350 mm
(92.5 in.)
2340 mm
(92.1 in.)
2350 mm
(92.5 in.)
2340 mm
(92.1 in.)
Wheel base 1610 mm (63.4 in.)
Minimum ground
clearance
235 mm
(9.3 in.)
225 mm
(18.9 in.)
235 mm
(9.3 in.)
225 mm
(18.9 in.)
235 mm
(9.3 in.)
225 mm
(18.9 in.)
Tread
Front 1030 mm (40.6 in.)
Rear
950 mm
(37.4 in.)
1070 mm
(42.1 in.)
965 mm
(38.0 in.)
1055 mm
(41.5 in.)
950 mm
(37.4 in.)
1070 mm
(42.1 in.)
965 mm
(38.0 in.)
1055 mm
(41.5 in.)
950 mm
(37.4 in.)
1070 mm
(42.1 in.)
965 mm
(38.0 in.)
1055 mm
(41.5 in.)
