STV32 · STV36 · STV40, WSM STEERING
7-S3
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : See page G-9.)
Item ft-lbs
Delivery hose RH retaining nut 24.5 to 29.4 2.5 to 3.0 18.1 to 21.7
Delivery hose LH retaining nut 24.5 to 29.4 2.5 to 3.0 18.1 to 21.7
Charge hose retaining nut 24.5 to 29.4 2.5 to 3.0 18.1 to 21.7
Delivery hose retaining nut (controller side) 34.3 to 44.1 3.5 to 4.5 25.3 to 32.5
Delivery hose retaining nut (pump side) 49 to 58.8 5.0 to 6.0 36.2 to 43.4
Steering controller hose joint (IN port) 34.3 to 49.0 3.5 to 5.0 25.3 to 36.2
Steering controller hose joint (LT port) 34.3 to 49.0 3.5 to 5.0 25.3 to 36.2
Steering controller hose joint (RT port) 34.3 to 49.0 3.5 to 5.0 25.3 to 36.2
Steering controller hose joint (OUT port) 24.5 to 34.3 2.5 to 3.5 18.1 to 25.3
0000007794E
