10. FINAL REDUCTION
10-3
AGILITY CITY 125
Check the left crankcase bearings for
excessive play and inspect the oil seal for
wear or damage.
Inspect the drive shaft and gear for wear or
damage.
Check the transmission case cover bearings
for excessive play and inspect the final shaft
bearing oil seal for wear or damage.
BEARING REPLACEMENT
(TRANSMISSION CASE COVER)
Remove the transmission case cover bearings
using a bearing puller.
Remove the final shaft oil seal.
Bearing Puller
Drive new bearings into the transmission case
cover.
Drive Shaft Bearing
Final Shaft Bearin
Countershaft Bearing
Drive Shaft Bearin
Do not remove the transmission case
cover except for necessary part replace-
ment. When replacing the drive shaft,
also replace the bearing and oil seal.
＊
Bearing Pulle
Oil Seal
Final Shaft Bearin
Countershaft Bearin
Outer Driver, 32x35m
Special
