13. REAR WHEEL/REAR BRAKE/
REAR SUSPENSION
13-1
AGILITY CITY 125
SERVICE INFORMATION
GENERAL INSTRUCTIONS
xDuring servicing, keep oil or grease off the brake drum and brake linings.
SPECIFICATIONS
Ite
m
Standard
(
mm
)
Service Limit
(
mm
)
Radial

2.0
Rear wheel Axial

2.0
Rear brake drum I.D 131 130
Rear brake linin
g
thickness 4.0 2.0
Rear shock absorber s
p
rin
g
free len
g
th 225 210
TORQUE VALUES
Rear axle nut 11~13kgf-m
Rear shock absorber upper mount bolt 3.5~4.5kgf-m
Rear shock absorber lower mount bolt 2.4~3.0kgf-m
Exhaust muffler joint lock nut 1.0~1.4kgf-m
Exhaust muffler lock bolt 3.0~3.6kgf-m
Special Tool
Cushion Assemble & Disassemble Tool
TROUBLESHOOTING
Rear wheel wobbling Poor brake performance
xBent rim x Brake not adjusted properly
xFaulty tire x Worn brake linings
xAxle not tightened properly x Worn brake shoes at cam contacting area
Soft rear shock absorber x Worn brake cam
xWeak shock absorber spring x Worn brake drum
xFaulty damper
SERVICE INFORMATION...................... 13-1 REAR BRAKE.........................................13-3
TROUBLESHOOTING............................. 13-1 REAR SHOCK ABSORBER...................13-4
REAR WHEEL.......................................... 13-2
Rim runout
