2. FRAME COVERS/EXHAUST MUFFLER
2-1
AGILITY CITY 125
SERVICE INFORMATION
GENERAL INSTRUCTIONS
xWhen removing frame covers, use special care not to pull them by force because the cover joint
claws may be damaged.
Items Related for Removal
xHandlebar front cover Handlebar rear cover
Headlight wire connector
xHandlebar rear cover Speedometer cable and instrument light
wire connectors, etc.
xFrame body cover Met-in box, rear grip, rear turn signal
lights, floor board
xFloor board Frame body cover
Battery and wire connectors
xLeg Shield Front cover, floor board
TORQUE VALUES
Exhaust muffler joint lock nut 1.0~1.4kgf-m
Exhaust muffler lock bolt 3.0~3.6kgf-m
SERVICE INFORMATION ...................... 2-1 EXHAUST MUFFLER REMOVAL .........2-5
FRAME COVERS ..................................... 2-2
