4. LUBRICATION SYSTEM
4-1
AGILITY CITY 125
SERVICE INFORMATION
GENERAL INSTRUCTIONS
xThe maintenance of lubrication system can be performed with the engine installed in the frame.
xUse care when removing and installing the oil pump not to allow dust and foreign matters to
enter the engine and oil line.
xDo not attempt to disassemble the oil pump. The oil pump must be replaced as a set when it
reaches its service limit.
xAfter the oil pump is installed, check each part for oil leaks.
SPECIFICATIONS
Item Standard (mm) Service Limit (mm)
Inner rotor-to-outer rotor clearance 0.12
Oil pump Outer rotor-to-pump body clearance 0.12
Rotor end-to-pump body clearance 0.05Д0.10 0.2
TROUBLESHOOTING
Oil level too low Poor lubrication pressure
xNatural oil consumption x Oil level too low
xOil leaks x Clogged oil filter or oil passages
xWorn or poorly installed piston rings x Not use the specified oil
xWorn valve guide or seal
