3. INSPECTION/ADJUSTMENT
3-0
AGILITY CITY 125
3
SERVICE INFORMATION
GENERAL
l WARNING
xBefore running the engine, make sure that the working area is well-ventilated. Never run the
engine in a closed area. The exhaust contains poisonous carbon monoxide gas which may
cause death to people.
xGasoline is extremely flammable and is explosive under some conditions. The working area
must be well-ventilated and do not smoke or allow flames or sparks near the working area or
fuel storage area.
SPECIFICATIONS
ENGINE
Throttle grip free play : 2Д6mm
Spark plug gap : 0.6Д0.7mm
Spark plug : NGK C7HSA
Valve clearance : IN: 0.12mm
:EX: 0.12mm
Idle speed : 1700 Ô100rpm
Engine oil capacity:
At disassembly : 0.9 liter
At change : 0.8 liter
Gear oil capacity :
At disassembly : 0.2 liter
At change : 0.18 liter
3
SERVICE INFORMATION....................3-0 FINAL REDUCTION GEAR OIL.......3- 7
MAINTENANCE SCHEDULE...............3-2 DRIVE BELT.........................................3- 7
FUEL FILTER..........................................3-3 BRAKE SHOE.......................................3- 8
THROTTLE OPERATION.....................3-3 BRAKE ADJUSTING NUT..................3- 8
AIR CLEANER ........................................3-4 HEADLIGHT AIM ...............................3- 9
SPARK PLUG ..........................................3-4 CLUTCH SHOE WEAR.......................3- 9
VALVE CLEARANCE............................3-5 SUSPENSION ........................................3- 9
CARBURETOR IDLE SPEED...............3-5 NUTS/BOLTS/FASTENERS................3-10
IGNITION TIMING ................................3-6 WHEELS/TIRES...................................3-10
CYLINDER COMPRESSION................3-6 STEERING HANDLEBAR..................3-11
Cortesia de / Courtesy of: www.batmotos.com
Recambios KYMCO en www.batmotos.com
