1. GENERAL INFORMATION
1-12
AGILITY CITY 125
SPECIAL TOOLS
Tool Name Tool No. Remarks Ref. Page
10-3
10-4Bearing puller 10.12.15.18 mm E037 10.12.15.18mm bearing
12-6
Bushing remover L E032 11102 bush engine hanger rubber
Bushing remover S EO19 11203 bush rear cushion under rubber
Crankshaft bearing puller E030 91005 radial bearing
Crankshaft protector E029 13000 crankshaft comp 12mm.14mm
Clutch spring compressor E027 2301a driven pully assy
9-9
9-12
Cushion assemble & disassemble
tool
F004 52400 cushion assy 13-4
Flywheel holder E017
31110 fl
y
wheel com
p
.2310a
p
ull
y
ass
y
driven
9-5
9-9
9-13
14-7
14-9
Flywheel puller E002 Left hand thread 27mm
14-7
Long socket wrench 32mm 8angle F002 50306 steering stem
12-21
12-22
Oil seal & bearing installer E014 Oil seal & bearing install
Tool boox E033 Special tools storage
Tappet adjuster E036 90012 screw tappet 3-5
7-7
Valve spring compressor E038 Valve spring
7-8
