12. FRONT WHEEL/FRONT BRAKE/
FRONT SUSPENSION
12-1
AGILITY CITY 125
SERVICE INFORMATION
GENERAL INSTRUCTIONS
xRemove the motorcycle frame covers before removing the front wheel. Jack the motorcycle
front wheel off the ground and be careful to prevent the motorcycle from falling down.
xDuring servicing, keep oil or grease off the brake drum and brake linings.
SPECIFICATIONS
Ite
m
Standard
(
mm
)
Service Limit
(
mm
)
Axle shaft runout

0.2
Radial

2.0
Front wheel rim runout
Axial

2.0
Front shock absorber s
p
rin
g
free len
g
th 230 226.5
TORQUE VALUES
Handlebar bolt 4.5~5.5kgf-m
Steering stem lock nut 6.0~8.0kgf-m
Steering top cone race 0.5~1.3kgf-m
Front shock absorber bolt 3.0kgf-m
Front axle nut 5.0~7.0kgf-m
Brake arm bolt 0.8~1.2kgf-m
SPECIAL TOOLS
Long socket wrench,32mm 8angle
SERVICE INFORMATION .................... 12-1 FRONT SHOCK ABSORBER................ 12-18
TROUBLESHOOTING........................... 12-2 FRONT FORK......................................... 12-21
STEERING HANDLEBAR..................... 12-3
FRONT WHEEL...................................... 12-4
