KYMCO PEOPLE S 125 Service Manual

9.DRIVE AND DRIVEN PULLEYS/
KICK STARTER
9-3
PEOPLE S 4T
LEFT CRANKCASE COVER
REMOVAL
Remove the bar assembly right rear step.
Remove the left crankcase cover bolts and
left crankcase cover.
Remove the seal rubber and dowel pins.
DRIVE PULLEY
REMOVAL
Hold the drive pulley using an universal
holder and remove the drive face nut and
starting ratchet.
Remove the drive pulley face.
Universal Holder
CLUTCH/DRIVEN PULLEY
Remove the drive pulley and drive belt.
Hold the clutch outer with the flywheel holder
and remove the clutch outer nut.
Remove the clutch outer.
Remove the clutch/driven pulley and drive
belt.
Flywheel Holder
Left Crankcase Cove
r
Step
Bolts
Drive Pulley Face
Universal Holde
r
Clutch Oute
r
Flywheel Holde
r
Screw
Special
Special
Starting Ratchet
