KYMCO PEOPLE S 125 Service Manual

7. CYLINDER HEAD/VALVES
7-5
PEOPLE S 4T
CAMSHAFT REMOVAL
Remove the center cover.
Remove the four cylinder head cover bolts
and secondary air inlet tube bolts to remove
the cylinder head cover.
Remove the cam chain tensioner cap screw
and the O-ring.
Turn the cam chain tensioner screw
clockwise to tighten it.
Turn the flywheel counterclockwise so that
the “T” mark on the flywheel aligns with the
index mark on the crankcase to bring the
round hole on the camshaft gear facing up to
the top dead center on the compression
stroke.
Cylinder Head Cove
r
O-ring
Tensioner Screw
Round Hole
Camshaft Gea
r
Punch Marks
Bolts
Bolts

KYMCO PEOPLE S 125 Specifications

General

Displacement	124.6 cc
Front Suspension	Telescopic Fork
Cooling System	Air Cooled
Max Torque	10.4 Nm @ 6500 rpm
Transmission	CVT
Front Brake	Disc
