1. GENERAL INFORMATION
1-3
PEOPLE S 4T
Ignition System
Transmis-
sion Gear
Reduction
Gear
SPECIFICATIONS
Name & Model No. PEOPLE S 50
Overall length (mm) 2010
Overall width (mm) 720
Overall height (mm) 1300
Wheel base (mm) 1360
Engine type O.H.C.
Displacement (cc) 49.5
Fuel Used
92# nonleaded
gasoline
Front wheel 42
Net weight (kg) Rear wheel 60
Total 102
Front wheel 43
Gross weight(kg) Rear wheel 66
Total 109
Front wheel 100/80-16 50P
Rear wheel 110/70-16 52P
Ground clearance (mm) 150
Perform- Braking distance (m) 4.4 (30km/h)
ance Min. turning radius
(m)
1.9
Starting system
Starting motor &
kick starter
Type
OHC air cooled 4-
cycle
Cylinder arrangement Single cylinder
Combustion chamber type Semi-sphere
Valve arrangement O.H.C., chain drive
Bore x stroke (mm) 39x 41.4
Compression ratio 11:1
Compression pressure
(kg/cm²)
18
Max. output (kw/rpm) 2.98/7500
Max. torque (N m/rpm) 3.82/7000
Intake Open 3°
Intake 0.04
(cold) (mm) Exhaust 0.04
Idle speed (rpm) 1700rpm
Lubrication type
Forced pressure &
wet sump
Oil pump type Inner/outer rotor type
Oil filter type Full-flow filtration
Oil capacity 0.85 liter
Exchanging
capacity
0.7 liter
Cooling Type Forced air cooling
Air cleaner type & No Paper element
Fuel capacity 6.7 liters
Type CVK
Piston dia. (mm) 17
Venturi dia.(mm) 16 equivalent
Throttle type Butterfly type
Type CDI
Ignition timing 13°~28°BTDC/2100rp
Contact breaker Non-contact point type
Spark plug NGK C7HSA
Spark plug gap 0.6～0.7mm
Battery Capacity 12V6AH
Clutch Type Dry multi-disc clutch
Type Non-stage
transmission
Operation
Automatic centrifugal
type
Type Two-stage reduction
Reduction 1st 0.895~3.113
ratio 2nd 14.69
Front Caster angle 25°
Axle Trail length
Tire pressure Front 1.75
(kg/cm²) Rear 2.00 (2.25)
Turning Left 45°
angle Right 45°
Brake system Front Disk brake
type Rear Drum brake
Suspension Front Telescope
type Rear Swing arm
Shock absorber Front Telescope
type Rear Swing arm
Frame type Steel pipe
Tires
