KYMCO PEOPLE S 125 Service Manual

5. FUEL SYSTEM
5-11
PEOPLE S 4T
FUEL TANK
REMOVAL
Remove the frame body cover.
Disconnect the fuel unit wire connector.
Disconnect the fuel tube and vacuum tube at
the auto fuel valve.
Remove the fuel tank frame mounting bolts
and fuel tank frame.
Remove the fuel tank mounting bolts and fuel
tank.
INSTALLATION
Install the fuel tank in the reverse order of
removal.
FUEL UNIT
REMOVAL
Disconnect the fuel unit wire connector.
Removal the four bolts on the fuel unit.
Fuel Unit Wire Connecto
r
Fuel Tank
A
uto Fuel Valve
Vacuum Tube
Refer to Section 17 for the fuel unit
inspection.
＊
Do not bend the fuel unit float arm;
otherwise, the fuel unit metering values
will be incorrect.
＊
Bolt

KYMCO PEOPLE S 125 Specifications

General

Displacement	124.6 cc
Front Suspension	Telescopic Fork
Cooling System	Air Cooled
Max Torque	10.4 Nm @ 6500 rpm
Transmission	CVT
Front Brake	Disc
