2. EXHAUST MUFFLER/FRAME COVERS
2-3
PEOPLE S 4T
FRAME COVERS REMOVAL
REAR CARRIER
Remove the met-in box.
First remove the two bolts and three nuts
attaching the met-in box.
Remove the met-in box.
Remove the three bolts attaching the rear
carrier.
Remove the rear carrier.
FRAME BODY COVER REMOVAL
Remove the two nuts attaching the rear
protective cover.
Remove the rear protective cover.
Remove the two screws on the bottom of the
center cover.
Remove the center cover.
Remove the body cover.
Nuts
Screws
Bolts
Carrie
r
Bolts
Protective Cove
r
Cente
r
Cove
r
Nuts
Body Cove
r
