KYMCO PEOPLE S 125 Service Manual

13 . REAR WHEEL/REAR BRAKE/
REAR SUSPENSION
13-6
PEOPLE S 4T
Remove the rear shock absorber upper and
lower mount bolts.
Remove the rear shock absorber.
ADJUSTABLE REAR CUSHION
To suit scooter behaviour to load condition
rear cushion could be adjusted in spring
prelocad.
It is possible to adjust rear cushion in three
positions:
A position “soft”
B position “medium”
C position “hard”
When you adjust rear cushion, the spring
preload of rear cushions must be the same.
INSTALLATION
Install the rear shock absorber. First install
the upper mount bolt and then the lower
mount bolts and tighten them.
Install the air cleaner case and tighten the two
bolts.
Install the frame body cover.
Torque:
Upper Mount Bolt: 4.0kg-m
Lower Mount Bolt: 2.7kg-m
Bolt
A
djust Position
Bolt
B
A
C
