16
. STARTING SYSTEM
16-2
PEOPLE S 4T
SERVICE INFORMATION
GENERAL INSTRUCTIONS
• The removal of starter motor can be accomplished with the engine installed.
• For the starter clutch removal, refer to Section 4.
SPECIFICATIONS
Item Standard (mm) Service Limit (mm)
Starter motor brush length 12.5 8.5
TORQUE VALUES
Starter clutch cover socket bolt 1.2kg-m
Starter clutch lock nut 9.5kg-m
SPECIAL TOOLS
Lock nut wrench
Universal holder
TROUBLESHOOTING
Starter motor would not turn Lack of power
• Fuse burned out • Weak battery
• Weak battery • Loose wire or connection
• Faulty ignition switch • Foreign matter stuck in starter motor
• Faulty starter clutch
or gear
• Faulty front or rear stop switch
• Faulty starter relay Starter motor rotates but engine does
• Poorly connected, broken or shorted wire
not start
• Faulty starter motor • Faulty starter clutch
• Starter motor rotates reversely
• Weak battery
