18
. EXHAUST EMISSION CONTROL
SYSTEM
18-4
PEOPLE S 4T
REED VALVE
REMOVAL
Remove the frame body cover.
Remove the floor-foot cover.
Disconnect the secondary air inlet tube
connector.
Remove the reed valve cover three bolts
and two secondary air outlet tube bolts.
Remove the three bolts attaching the reed
valve cover and the reed valve.
INSPECTION
Check the reed valve for cracks, damage,
big clearance or weak reeds. Replace if
necessary.
Check the gasket and O-ring for damage or
deterioration and replace if necessary.
Reed valve stopper clearance: 4.6mm
INSTALLATION
Install the reed valve in the reverse order of
removal.
Cylinder Head Cove
• When installing, be careful not to bend
or twist the tubes and check for prope
